DTC's large diameter well consists essentially of 260 ft of 18.5/8" casing.
Well Summary
- Elevations:
Rotary Table - ground level = 30 ft
Rotary Table - base of cellar = 39 ft
- Total Depth:
305 ft (Driller's Measured Depth) from rotary table.
- Well Status:
18.5/8" casing set at 264 ft.
- Hole Sizes:
- Wellhead:
No wellhead has been installed on the 18.5/8" casing stub.
- Casing:
- 30" conductor pipe: 1 "wall, X-52, welded.
Shoe Depth 85 ft, cemented back to the cellar floor.
- 18.5/8" casing: 87.5 obs/ft X-56, GEM.
Shoe depth 264 ft, cemented back into the 30" pipe, later cemented to cellar floor with ready-mixed concrete.
- The 18.5/8" casing has not been cleaned out with a 17.1/2" bit.
- PBTD is estimated to be 262 ft.
